SDS-D/S性能参数表
|
|
SDS — D 单向通风型
|
|
型号No.
|
叶角代号
|
转速rpm
|
风量m 3 /s
|
轴向推力N
|
出口风速m/s
|
单速功率KW
|
噪声dBA
|
双速功率KW
|
|
5.6
|
1
|
2900
|
8.6
|
385
|
35.1
|
11
|
75
|
12.5 / 2.8
|
|
1450
|
4.1
|
87
|
16.8
|
1.5
|
63
|
|
2
|
2900
|
7.8
|
315
|
31.7
|
7.5
|
73
|
8 / 2
|
|
1450
|
3.8
|
76
|
15.6
|
1.1
|
61
|
|
3
|
2900
|
7.0
|
245
|
28.4
|
5.5
|
71
|
--
|
|
4
|
2900
|
6.2
|
200
|
25.2
|
4
|
68
|
--
|
|
6.3
|
1
|
2900
|
11.8
|
540
|
37.8
|
15
|
75
|
16 / 3.8
|
|
1450
|
5.5
|
139
|
17.6
|
2.2
|
63
|
|
2
|
2900
|
10.5
|
430
|
33.6
|
11
|
73
|
12.5 / 2.8
|
|
1450
|
5.0
|
102
|
16.1
|
1.5
|
61
|
|
3
|
2900
|
9.2
|
330
|
29.5
|
7.5
|
71
|
--
|
|
4
|
2900
|
8.2
|
260
|
26.4
|
5.5
|
68
|
--
|
|
7.1
|
1
|
2900
|
14.8
|
660
|
37.4
|
18.5
|
75
|
16 / 3.8
|
|
1450
|
7.1
|
162
|
17.9
|
2.2
|
63
|
|
2
|
2900
|
13.5
|
550
|
34.1
|
15
|
73
|
16 / 3.8
|
|
1450
|
6.3
|
131
|
15.9
|
1.5
|
61
|
|
3
|
2900
|
12.1
|
435
|
30.6
|
11
|
72
|
--
|
|
4
|
2900
|
10.5
|
340
|
26.5
|
7.5
|
69
|
--
|
|
8
|
1
|
1450
|
14.8
|
55.
|
29.5
|
15
|
75
|
15.5 / 5.1
|
|
960
|
10.0
|
240
|
19.9
|
4
|
68
|
|
2
|
1450
|
13.8
|
475
|
27.5
|
11
|
74
|
12 / 4
|
|
960
|
9.1
|
210
|
18.1
|
3
|
67
|
|
3
|
1450
|
12.2
|
375
|
24.3
|
7.5
|
72
|
--
|
|
4
|
1450
|
11.0
|
300
|
21.9
|
5.5
|
70
|
--
|
|
|
|
|
型号No.
|
叶角代号
|
转速rpm
|
流量 m 3 /s
|
轴向推力N
|
出口风速m/s
|
单速功率KW
|
噪声 dBA
|
双速功率KW
|
|
9
|
1
|
1450
|
21.1
|
870
|
33.2
|
22
|
75
|
24 / 8.5
|
|
960
|
13.8
|
380
|
21.7
|
7.5
|
68
|
|
2
|
1450
|
19.2
|
735
|
30.2
|
18.5
|
73.5
|
18 / 6.2
|
|
960
|
12.4
|
315
|
19.5
|
5.5
|
66
|
|
3
|
1450
|
17.3
|
600
|
27.2
|
15
|
71
|
--
|
|
4
|
1450
|
14.2
|
410
|
22.3
|
7.5
|
68
|
--
|
|
10
|
1
|
1450
|
27.6
|
1130
|
35.1
|
30
|
75
|
33 / 11
|
|
960
|
18.2
|
490
|
23.2
|
11
|
68
|
|
2
|
1450
|
23.2
|
800
|
29.5
|
22
|
73
|
24 / 8.5
|
|
960
|
14.8
|
340
|
18.8
|
5.5
|
66
|
|
3
|
1450
|
20.4
|
670
|
26.0
|
15
|
71
|
--
|
|
4
|
1450
|
18.8
|
550
|
23.9
|
11
|
68
|
--
|
|
11.2
|
1
|
1450
|
34.8
|
1370
|
35.5
|
37
|
75
|
38 / 13
|
|
960
|
22.1
|
600
|
22.8
|
11
|
68
|
|
2
|
1450
|
31.4
|
1100
|
32.1
|
30
|
73.5
|
33 / 11
|
|
960
|
19.6
|
465
|
20.2
|
7.5
|
67
|
|
3
|
1450
|
27.4
|
900
|
27.9
|
22
|
72
|
--
|
|
4
|
1450
|
24.4
|
710
|
25.0
|
15
|
69
|
--
|
|
12.5
|
1
|
1450
|
42.4
|
1690
|
34.6
|
45
|
75
|
47 / 16
|
|
960
|
27.2
|
740
|
22.2
|
15
|
68
|
|
2
|
1450
|
37.8
|
1350
|
30.8
|
37
|
73.5
|
38 / 13
|
|
960
|
24.2
|
590
|
19.8
|
11
|
67
|
|
3
|
1450
|
32.2
|
1005
|
26.3
|
22
|
71
|
--
|
|
4
|
1450
|
30.4
|
880
|
24.8
|
18.5
|
69
|
--
|
|
|
SDS — S 双向通风型
|
|
型号No.
|
叶角代号
|
转速 rpm
|
流量 m 3 /s
|
轴向推力 N
|
出口风速m/s
|
装机功率KW
|
噪声dBA
|
双速功率KW
|
|
5.6
|
1
|
2900
|
8.4
|
340
|
34.1
|
11
|
75
|
12.5 / 2.8
|
|
1450
|
4.0
|
82
|
16.2
|
1.5
|
63
|
|
2
|
2900
|
7.6
|
280
|
30.9
|
7.5
|
73
|
8 / 2
|
|
1450
|
3.7
|
71
|
15.1
|
1.1
|
61
|
|
3
|
2900
|
6.7
|
210
|
27.2
|
5.5
|
71
|
--
|
|
4
|
2900
|
6.0
|
175
|
24.2
|
4
|
68
|
--
|
|
6.3
|
1
|
2900
|
11.2
|
480
|
35.8
|
15
|
75
|
16 / 3.8
|
|
1450
|
5.4
|
117
|
17.3
|
2.2
|
63
|
|
2
|
2900
|
10.0
|
375
|
32.0
|
11
|
73
|
12.5 / 2.8
|
|
1450
|
4.6
|
85
|
14.7
|
1.5
|
61
|
|
3
|
2900
|
8.6
|
280
|
27.5
|
7.5
|
71
|
--
|
|
4
|
2900
|
7.8
|
230
|
25.0
|
5.5
|
68
|
--
|
|
7.1
|
1
|
2900
|
13.3
|
555
|
33.7
|
18.5
|
75
|
16 / 3.8
|
|
1450
|
6.5
|
132
|
16.4
|
2.2
|
63
|
|
2
|
2900
|
12.2
|
465
|
30.8
|
15
|
73
|
16 / 3.8
|
|
1450
|
6.0
|
112
|
15.2
|
1.5
|
61
|
|
3
|
2900
|
10.8
|
365
|
27.3
|
11
|
72
|
--
|
|
4
|
2900
|
9.5
|
285
|
24.1
|
7.5
|
69
|
--
|
|
8
|
1
|
1450
|
13.8
|
450
|
29.5
|
15
|
75
|
15.5 / 5.1
|
|
960
|
8.9
|
200
|
19.9
|
4
|
68
|
|
2
|
1450
|
12.8
|
390
|
27.5
|
11
|
74
|
12 / 4
|
|
960
|
8.3
|
170
|
18.1
|
3
|
67
|
|
3
|
1450
|
11.0
|
24.3
|
310
|
7.5
|
72
|
--
|
|
4
|
1450
|
10.0
|
250
|
21.9
|
5.5
|
70
|
--
|
|
|
|
|
型号No.
|
叶角代号
|
转速rpm
|
流量m 3 /s
|
轴向推力N
|
出口风速m/s
|
单速功率KW
|
噪声 dBA
|
双速功率KW
|
|
9
|
1
|
1450
|
19.4
|
725
|
33.2
|
22
|
75
|
24 / 8.5
|
|
960
|
12.0
|
315
|
21.7
|
7.5
|
68
|
|
2
|
1450
|
17.6
|
610
|
30.2
|
18.5
|
73.5
|
18 / 6.2
|
|
960
|
11.2
|
260
|
19.5
|
5.5
|
66
|
|
3
|
1450
|
16.0
|
550
|
27.2
|
15
|
71
|
--
|
|
4
|
1450
|
12.4
|
340
|
22.3
|
7.5
|
68
|
--
|
|
10
|
1
|
1450
|
24.8
|
950
|
35.1
|
30
|
75
|
33 / 11
|
|
960
|
16.2
|
415
|
23.2
|
11
|
68
|
|
2
|
1450
|
22.1
|
750
|
29.5
|
22
|
73
|
24 / 8.5
|
|
960
|
13.8
|
330
|
18.8
|
5.5
|
66
|
|
3
|
1450
|
18.8
|
550
|
26.0
|
15
|
71
|
--
|
|
4
|
1450
|
17.4
|
450
|
23.9
|
11
|
68
|
--
|
|
11.2
|
1
|
1450
|
32.2
|
1220
|
32.7
|
37
|
75
|
38 / 13
|
|
960
|
20.5
|
530
|
21.0
|
11
|
68
|
|
2
|
1450
|
30.2
|
1080
|
30.7
|
30
|
73.5
|
33 / 11
|
|
960
|
19.6
|
475
|
20.0
|
7.5
|
67
|
|
3
|
1450
|
26.1
|
805
|
26.5
|
22
|
72
|
--
|
|
4
|
1450
|
22.8
|
640
|
23.1
|
15
|
69
|
--
|
|
12.5
|
1
|
1450
|
40.2
|
1470
|
32.8
|
45
|
75
|
47 / 16
|
|
960
|
25.4
|
640
|
20.7
|
15
|
68
|
|
2
|
1450
|
37.2
|
1260
|
30.3
|
37
|
73.5
|
38 / 13
|
|
960
|
23.2
|
550
|
18.9
|
11
|
67
|
|
3
|
1450
|
30.1
|
860
|
24.5
|
22
|
71
|
--
|
|
4
|
1450
|
28.1
|
750
|
22.9
|
18.5
|
69
|
--
|
|
